CL-HG-001-CNArchitectural Hardware > Hinges
Cast Hinge 102
£24.50
Finish
Cast Nickel
In stock — dispatched in 1–3 working daysFree UK delivery over £200
Order a £20 finish sample — credited against your order
Guarantee
Termless guarantee · see terms
Made
Made to our specification by our manufacturing partner, to the spec on this page.
A Grade 13 ball bearing hinge, finish-matched to the full Cast range. 102 × 76 × 3 mm, fire rated for 30 and 60 minute doors. Supplied in packs of three. Built to specification standard.
- 102 × 76 × 3 mm
- Grade 13 to BS EN 1935:2002
- Doors up to 120 kg
- Certifire approved (CF547) — FD30 / FD60 fire doors
- CE and UKCA marked
- Twin ball bearings, button tips
- Pack of three, fixings included
Range
Cast
Material
Steel
Grade
13 · BS EN 1935:2002
Fire rating
FD30 / FD60
Certification
Certifire CF547 · CE · UKCA
Hinge size
102 × 76 mm
Leaf thickness
3 mm
Knuckle diameter
14 mm
Bearings
Twin ball bearings
Max door mass
120 kg
Application
Timber
Use
Interior
Pack quantity
3 · supplied as a set
Supplied with
Full fixing pack
Guarantee
Termless
Fire rated for use on FD30 and FD60 timber fire doors. Certifire CF547. Fire test certificate available on request — studio@castlondon.co.uk.
